Product description This historic book may have numerous typos and missing text. Purchasers can download a free scanned copy of the original book (without typos) from the publisher. Not indexed. Not illustrated. 1906 Excerpt:...therefore the product volts X amperes is not the true power. There are several means for determining the true power of an A. C. circuit, the simplest being an indicating wattmeter. A wattmeter is an electro-dynamometer provided with two coils, a fixed one of coarse wire, the other movable and of line wire. This movable coil is connected in series with a large non-inductive resistance, so that the time-constant of the fine-wire circuit is extremely small; and hence its impedance is practically equal to its resistance; the current in, and resulting field of, the fine-wire coil will under these conditions be practically in phase with the potential difference across its terminals. The field produced by the coarse-wire coil is directly proportional to the current flowing through it at any instant. Hence, the couple acting on the finewire coil is proportional at a given instant to the product of these fields; so that the reading of the instrument, which depends on the mean value of the couple, will be proportional to the mean power, and, by providing the instrument with the proper scale, it can be made to read directly in watts. In Fig. 52, A 13 represents an inductive load--say, a singlephase motor--of which the power input is to be determined; 0 I) the terminals of the thick-wire coil (current-coil) of the wattmeter; and E F the pressure-coil terminals. When connected as above indicated, the wattmeter indicates directly the power in watts supplied. In the case of a two-phase system, where the two circuits are independent, the power may be measured by placing a wattmeter in each phase, as shown in Fig. 52, and adding the two readings. If the motor be connected up as shown in Fig. 53, where A E forms a common return, the wattmeters are placed aa i
