In recent years, the mobile phone manufacturers have increasingly focused on thinner and more mechanically mixed products. These devices need to be able to be operating with several different mobile phone systems and in different frequency bands. Based on the evolution in the wireless industry, the handsets need also to be equipped with other wireless functionality such as WLAN, Bluetooth, and GPS. In order to work in multi-band wireless systems, the design of the mobile phone antenna becomes a key issue.Based on the work by Vilanen et al., a small, low profile and efficient coupling element based antenna with penta-band operations for the use in mobile telephones has been studied in this book. The antenna was designed by a High Frequency Structure Simulator, HFSS, built and verified. Cases with different antenna dimensions also have been investigated for the coupling affection. The resulting antennas operate over two wide bands from (824-1300) MHz and from (1710-2170) MHz, covering five cellular bands (GSM850/900/1800/PCS1900 and UMTS).
This book investigates the design and performance of a penta-band mobile phone antenna capable of operating across multiple cellular frequency bands. Authored by Hai Zhao, this work details the study of a small, low-profile, and efficient coupling element-based antenna for mobile telephones, building upon prior research. The antenna was designed using High Frequency Structure Simulator (HFSS), subsequently built and verified, with investigations into various antenna dimensions and their coupling effects. The resulting antennas demonstrate operation over two wide bands, covering five cellular bands essential for modern multi-band wireless systems.
This technical monograph presents a focused study on antenna design for multi-band mobile communication devices. The work details a specific engineering solution, the coupling element-based penta-band antenna, and its validation through simulation and physical testing. The research addresses the increasing demand for compact, efficient antennas in modern, feature-rich mobile handsets.
Page Count:
68
Publication Date:
2009-06-26
Publisher:
VDM Verlag
ISBN-10:
3639167430
ISBN-13:
9783639167436
