Author Description

This report describes a study designed to address four research questions about symbology for electronic displays of charting information. The main research question was whether pilots could identify a set of test symbols. Three other research questions were addressed regarding: (1) labels for navigation aid symbols, (2) grouping navigation aids into families, and (3) line style conventions on paper charts and electronic moving map displays.
