Author Description

Modelling with AutoCAD 2004 is a course based on learning and practising the techniques of 3D modelling using AutoCAD. Bob McFarlanes' hands-on approach is uniquely suited to independent learning and use on courses. The focus on 3D drawing in one book, ensures the reader gets a thorough grounding in the subject, with a greater depth of coverage of 3D design than tends to be available from general introductions to AutoCAD. As a result, this book provides a true, step-by-step, detailed exploration of the AutoCAD functions required at each stage of producing a 3D drawing, an approach often not found in the many software reference guides available. The emphasis on learning through doing makes this book ideal for anyone involved in engineering, construction or architecture where the focus is on productivity and practical skills. The author has also matched the coverage to the requirements of City and Guilds, Edexcel (BTEC) and SQA syllabuses. New features in AutoCAD 2004 are covered in this book, making it a useful refresher course for anyone using AutoCAD at this level, and those upgrading to the new software release. The course is also designed to be fully relevant to anyone using other recent releases, including AutoCAD 2002. Bob McFarlane is Curriculum Manager for CAD and New Media at Motherwell College, Scotland, and an Autodesk Educational Developer. This work presents a complete course on 3D design with AutoCAD in one book ideal for independent learning. The exercises are included throughout to aid student learning and self assessment. The focus on 3D drawing techniques provides in-depth coverage to this specialised use of AutoCAD.
