Author Description

Hydraulic Design Series Number 5 (HDS 5) originally merged culvert design information contained in Hydraulic Engineering Circulars (HEC) 5, 10, and 13 with other related hydrologic, storage routing and special culvert design information. This third edition is the first major rewrite of HDS 5 since 1985, updating all previous information and adding new information on software solutions, aquatic organism passage, culvert assessment, and culvert repair and rehabilitation. The result is a comprehensive culvert design publication. This publication contains the equations and methodology used in developing the design charts (nomographs) and software programs, information on hydraulic resistance of culverts, the commonly used design charts, and Design Guidelines (DG) illustrating various culvert design calculation procedures.
