Reconfigurable machines can accelerate many applications by adapting to their needs through hardware reconfiguration. Partial reconfiguration allows the reconfiguration of a portion of a chip while the rest of the chip is still working. Operating system for partially reconfigurable machines (OS4RC) handles the scheduling and placement of tasks. Some existing OS4RC models assume no data exchange channel between IP (Intellectual Property) circuits residing on a FPGA chip and between an IP circuit and FPGA I/O pins. Other models assume inter-IP communication channels, but they do not work well with 2-D partial reconfiguration. And frequently they are very complicated to design and expensive. To address these problems, a new chip architecture that can better support inter-IP and IP-I/O communication is proposed and a corresponding OS4RC kernel is then specified.The proposed FPGA architecture is based on an array of clusters of CLBs, with each cluster serving as a partial reconfiguration unit, and a mesh of segmented buses that provides inter-IP and IP-I/O communication channels. Features of the new architecture can reduce the kernel execution times and enable the runtime scheduling,
This work proposes a novel FPGA architecture designed to enhance the efficiency of two-dimensional partial reconfiguration by facilitating robust inter-component communication. The author addresses limitations in existing operating systems for partially reconfigurable machines (OS4RC), which often lack effective data exchange channels between Intellectual Property (IP) circuits or between IPs and FPGA I/O pins, or are overly complex and costly. The proposed architecture utilizes an array of CLB clusters as partial reconfiguration units, interconnected by a mesh of segmented buses to provide necessary communication pathways. This design aims to reduce kernel execution times and enable more dynamic runtime scheduling for reconfigurable systems.
This technical monograph presents a specific hardware architecture and associated operating system kernel for enhancing two-dimensional partial reconfiguration in FPGAs. The work focuses on addressing communication bottlenecks between reconfigurable components and I/O pins, a common challenge in such systems. The proposed solution offers a structured approach to managing these complexities, aiming for improved performance and design efficiency. The detailed architectural design and kernel specification suggest a resource intended for researchers and engineers in the field of hardware acceleration and reconfigurable computing.
Page Count:
140
Publication Date:
2011-06-01
Publisher:
Lap Lambert Academic Publishing GmbH KG
ISBN-10:
384432870X
ISBN-13:
9783844328707
